تله هیدرولیک تله ابزار دستی برای تجهیزات کنترل فشار سر چاه فولاد آلیاژی
تماس با شخص : LEE
شماره تلفن : 86-13659253658
WhatsApp : +8613659253658
مقدار حداقل تعداد سفارش : | 1 ست | قیمت : | USD 1-10000/set |
---|---|---|---|
جزئیات بسته بندی : | وابسته به پولیوود | زمان تحویل : | 30-50 روز |
شرایط پرداخت : | L/C ، T/T ، D/P | قابلیت ارائه : | 10 مجموعه در ماه |
محل منبع: | چین | نام تجاری: | ZZ TOP OIL TOOLS |
---|---|---|---|
گواهی: | ISO, API | شماره مدل: | سر کنترل تزریق گریس |
اطلاعات تکمیلی |
|||
محصول: | سر کنترل تزریق گریس | مادی: | فولاد آلیاژ |
---|---|---|---|
فشار: | 10000psi | کاربرد: | عملیات سیمی |
استفاده: | تجهیزات کنترل فشار خط سیم | پیوستگی: | اتحادیه چکش |
دمای کارینگ: | -29 × 121 ℃ | ||
برجسته کردن: | 10000psi Grease Injection Control Head,Hammer Union Grease Injection Control Head,Alloy Steel Wireline Pressure Control Equipment,Hammer Union Grease Injection Control Head,Alloy Steel Wireline Pressure Control Equipment |
توضیحات محصول
The Grease Injection Control Head is a sealing device designed for braided cable wireline operations, providing effective wireline sealing functionality. This essential component is used across various oil and gas well applications where pressure control is critical during wireline operations, particularly when fluid or gas loss cannot be tolerated.
Wire Size | Working Pressure | Qty. Of Stuffing Box | Qty. Of Flow Tubes | Qty. Of Hydraulic Port | Qty. Of Grease Injection Port | Qty. Of Grease Return Port | Service | Working Temperature |
---|---|---|---|---|---|---|---|---|
7/32" 5/16" 15/32" |
5000Psi | 1 | 4 | 2 | 1 | 1 | STD or H2S | P+U -20°F~+250°℉ Or As Required |
10000Psi | 1 | 6 | 2 | 1 | 1 | |||
15000Psi | 2 | 9 | 3 | 2 | 1 |
